OriPure OLD-SR Alnico 5 Prewired Guitar Pickguard SSS Set (Hot Rails-Single Coil-Hot Rails).Fit for American Standard FD Strat SSS Style Guitar Parts Replacement.11 Holes SSS Pickguard Comes with Full Set of Pickups,Switch,Knobs and Prewired Circuit.OriPure PB5 Dual Rails Humbucker Pickups (Neck&Bridge) and OriPure TFF566 Flat Top Single Coil Pickup(Middle).Alnico 5 Magnet,Resistance:6.2k/6.1k/8.9k (N/M/B); Inductance: 4.2h/2.4h/5.3h (N/M/B).Use 24-Pin 5-way super switch to implement humbuckers coil splitting.2T1V control knobs, two A500k pots for tone ,one B500k pot for volume, MKP 473J 400v capacitor.Using cloth braid push-back wire connect,better reduce circuit noise.All you have to do is solder the input jack and your ready to play.Specification:Pickguard Color: Black 3ply, White 3ply, Cream 3ply,White Pearl 4ply, Red Tortoise 4ply colors for choose.Pickguard Material:Black/White/Cream are made of 3ply PVC, White Pearl/ Tortoise are made of 3ply PVC and 1ply celluloid.Note: The aluminum foil shield on backside is not flat; it is with some creases and patches caused during the processing.5-Way Super Switch Settings:Position 1: Bridge Humbucker FullPosition 2: Bridge Humbucker Coil Splitting (outer coil) and Middle Single CoilPosition 3: Middle Single CoilPosition 4: Middle Single Coil and Neck Humbucker Coil Splitting (inner coil)Position 5: Neck Humbucker FullPackage Includes:1 * Prewired SSS Pickguard Set1 * Screws Bag
