OriPure Small Double Track Alnico5 Dual Pickup RSR Set,N10.6+M6.5(R)+B13.6

Features:

Brand:OriPure .
Dual Hot Rails Guitar Pickup Fit For ST / SQ Style Electric Guitar Parts Upgrade or Replace.
These dual-rail humbuckers have all the benefits of a humbucker—increased output, low noise—all in a standard single-coil sized pickup.
The middle pickup is reverse wound and reverses polarity (RwRP) for hum cancellation at the #2 and #4 switch positions.

Neck Pickup and Bridge Pickup
Magnet: Alnico 5 (V) .
can use for Neck / Middle/ Bridge position:
Resistance 1: 10-11K .Inductance: 4.2H.
Resistance 2: 15-16K .Inductance: 10.5H.
Bobbin: Fiber Plate Bobbin.
Cable:4-conductor insulated lead wire for multiple wiring options.
Color :White/Black/Cream/Full Black
Fully Wax Potted to suppress noise.
Height adjustment screws, springs included.

Middle Pickup:
Resistance:6.5K
Inductance H: 2.8H
Winding:Reverse (RWRP)
Position: Middle
Color: White/Black/Cream
Magnet: Alnico 5 (Alnico V).
Pole Pieces: Staggered pole pieces.
Pole Spacing: 52mm

Package Includes:
3 x Pickup

Note:
1.All parameters for reference, the actual may be a bit deviation .  The actual effect of tone will be a little different from different guitars or related equipment .
2.The DC Resistance we marked will change due to the difference in ambient temperature, and the range of change will reach 500Ω. In case of extreme temperature, the range of change will be greater.
